Inland / Coastal Barge 25.40, Rhine certified

Dimensions (m): 25.40 x 5.00 x 1.15

Ref. no.: 240503

Mooring: Near South Netherlands

Construction year: 1902

Material: steel

Price: € 99.500,--

VAT not applicable

Download PDF folder

Vision Doeve Brokers

Former sailing estuary freighter / coaster that was built to supply the German Wadden Islands. In 1953 the ship was extended and provided with a raised stern and she was also remotorised. In the 1970s she was put into use as a workship with a crane on deck. This Dutch Barge has been in use as a cruising houseboat since 1985. The current owner sails with the ship throughout Western Europe and has even been to Briare, France. This can be done after everything that can be dismantled to achieve the lowest possible air draft has been removed. She is ready to go. The aft cabin is now in use as a workshop and eventually this could become a cabin again. It is a fully autonomous ship with, among other things, solar panels, generator, inverter, etc. etc. Fully Rhine certified.

More information

General information

Yard: Shipyard G en H Bodewes, NL-Martenshoek

Hull shape: flatbottom

Hull material: iron/steel

Deck material: iron/steel

Superstructure material: steel

Construction method: riveted
new steel is welded
rubbing strake around
bulwark
wide side decks (gunnels)
canoe stern
closed bollard cabinets
Sturdy, heavily constructed
1 watertight bulkhead(s) with watertight door(s)
1 watertight bulkhead(s)

Steering system: mechanical
wheel
steel rudder
attached rudder

Windows: portholes
wood window frames

Displacement (approx.): 58 m³

Ballast (approx.): poured concrete

Airdraft (approx.): 4,30 m
3,49 m everything down

Owner: British owner

Registration: SSR German registered
Costs for the change of ownership and / eventually deletion are for purchasers amount.

Colour / Paint System: black hull
blue bulwark
white superstructure
one component system
underwater ship completely stripped (hydrojet)
two component system
last underwatership treatment 10-2023

Certificates: Union Inland Navigation Certificate (ES-TRIN)
zone 3
zone 4
zone R (Rhine)
valid until: 03-2027

Suitable for / as: inland waterways
coastal waters
suitable as a year round live- aboard
& recreational vessel

General information: Old age clause applicable.
The ship is recognized as a Historic Vessel

Additional information: Hull shape is suitable for drying out.
spacious aftdeck
spacious upperdeck
Great vessel for cruising on the European canals and rivers.
Great vessel for cruising on the coastal waters.

Technical information

Enginepower: 120 Hp
88 kW

Engine brand: Mercedes

Revolutions: 1200 RPM

Engine model: M204B

Number of cylinders: 4

Construction year engine: 1957

Running hours (approx.): unknown

Fuel: diesel

Fuel tank (approx.): 1500 litre
2 steel tank(s)
sludge trap(s)
low level alarm

Cooling system: closed
keel cooling
dry exhaust
insulated exhaust

Propulsion: 3 blade propeller
greased lubrication of propeller shaft
2022 shaft bearing

Gearbox: Reintjes BOU
reduction/ratio 2:1

Speed (approx.): 9 km/hour cruising speed at 700 RPM
14 km/hour top speed

Heating: Kabola B12 stove on diesel
floor heating
& central heating (niet/not/nicht/ne pas 100%)

Bow thruster: Duco electric bow thruster
7,5 kW
400 Volt
proportional

Electricity system: 24 / 230 / 400 Volt
230 Volt shore power connection
400 Volt shore power connection

Batteries: 2x 180 Ah starter batterie(s)
1x 74 Ah starter batterie(s) generator
4x 190 Ah AGM domestic batterie(s) (03-2024)
Victron battery balancer
battery monitor

Battery charger: Victron MultiPlus combi inverter/charger 24/3000/70

Isolation transformer: Victron isolation transformer 3600 Watt

Earth-leakage breaker: present

Genny: Hatz whisper set
10 kVA 230/400 Volt
1500 RPM

Inverter: Victron MultiPlus combi inverter/charger 24/3000/70

Solar panels: 6x solar panel

Fresh water tank (approx.): 3400 litre
2 steel tank(s)
coated

Water pressure system: hydrophore pump

Hot water system: boiler/water calorifier (230 Volt)

Holding tank (approx.): 450 litre
1 plastic tank(s)

Bilge pump: electric pump
also deckwash pump
2x submersible pump

Gas system: no gas on board

Additional information: air compressor

Accommodation

Interior: Plywood
ceiling with laths (classic)

Insulation: hard foam plates

Cabins: 2 cabins

Berth: Forward: 2x 1-pers
Midships: 1x 2-pers & 2x 1-pers

Lay-out plan (not to scale): see attachment

Bathroom: shower
thermostat tap
washbasin with mixer tap and hot & cold running water
in 1 area together with the toilet

Toilet / Heads: toilet in bathroom

Galley: U-shape galley

Cooker: 2-burner hob
induction cooker

Oven: microwave/oven

Fridge / Refrigerator: present
230 Volt

Freezer: present
230 Volt

Washbasin: 2x stainless steel sink

Water tap: mixer tap with hot & cold running water

Entertainment: 2x flatscreen TV

Headroom (approx.): wheelhouse (approx.) 2,03 m / 1,86 m
galley (approx.) 2,19 m
salon (approx.) 1,93 m
bathroom / toilet (approx.) 2,01 m
cabin (approx) 2,24 m
forward cabin (approx.) 1,84 m
aftcabin (approx.) 1,97 m

Additional information: The vessel will be delivered with everything on board less personal effects & artwork.
washing machine
