Schooner Brig 40 pass
Dimensions (m):
29.00/24.95 x 5.76 x 2.20
Ref. no.:
230801
Mooring:
Near Zwolle, Netherlands
Construction year:
1936
Material:
steel
Price:
€ 199.500,--
price excl. VAT
Vision Doeve Brokers
Sailing charter ship for the inland waterways that can be used immediately for sailing with day passengers and is excellent for parties on board. There is a bar in the wheelhouse, in the salon (in the old hold) is sufficient seating and the main bar, and the toilet group is situated over there as well with the galley further forward. There is a spacious aft cabin that can function as the residence for the owner or can be used by guests as a lounge area. The seller provided the vessel with new sails in 2022 and fully recertified the vessel in May 2023, making the Dutch ES-TRIN certificate valid until 06-2028. With the impressive sail plan, this ship is a pearl on the water that makes many people look back. In our eyes an excellent passenger ship where someone can possibly live on board and use her for chartering.
More information
General information
| Yard: | Shipyard De Dageraad, NL-Woubrugge |
| Hull shape: | round bilged |
| Hull material: | steel |
| Deck material: | steel |
| Superstructure material: | steel wooden wheelhouse |
| Construction method: | riveted new steel is welded bulwark rubbing strake around wide side decks (gunnels) closed bollard cabinets 2 watertight bulkhead(s) 1 watertight bulkhead(s) with watertight door(s) |
| Keel: | bar keel / keel |
| Steering system: | hydraulic wheel & electric steering inside and outside steering position |
| Windows: | brass window frames brass portholes |
| Displacement (approx.): | maximum allowable displacement 165,304 m³ displacement in empty condition 145,846 m³ displacement 19,458 m³ |
| Ballast (approx.): | poured concrete |
| Airdraft (approx.): | 20,00 m |
| Owner: | Dutch owner |
| Registration: | Dutch registered B-registered Costs for the change of ownership and / eventually deletion are for purchasers amount. |
| Colour / Paint System: | black hull bordeaux red bulwark bordeaux red superstructure well maintained see photographs last underwatership treatment 05-2023 |
| Certificates: | inland waterways certificated (TRIWV / ES-TRIN) zone 2, 3 & 4 NL Waal, Lek & NL Rhine valid until: 06-2028 |
| Suitable for / as: | passengers vessel suitable as a year round live- aboard inland waterways |
| General information: | offered in the condition that she is in Sellers are possibly willing to part finance. |
| Additional information: | classic lines spacious aftdeck wheelhouse forepeak with chain locker The relevant VAT will be due on the asking price if the vessel is purchased by a consumer or by a Dutch company (provided it concerns a Dutch seller). Sale at 0% VAT to a is eventually possible if the buyer meets the applicable VAT guidelines. 40 day guests |
Technical information
| Enginepower: | 164 Hp 121 kW |
| Engine brand: | Deutz |
| Revolutions: | 600 RPM |
| Engine model: | AM428 air started |
| Running hours (approx.): | unknown |
| Fuel: | diesel |
| Fuel tank (approx.): | 1x 1500 litre steel tank(s) 1x 500 litre steel tank(s) sludge trap(s) |
| Cooling system: | intercooling dry exhaust insulated exhaust |
| Propulsion: | 3 blade propeller greased lubrication of propeller shaft |
| Gearbox: | Reintjes hydraulic |
| Speed (approx.): | 6 knots cruising speed at 350 RPM |
| Heating: | Fer central heating on diesel |
| Bow thruster: | DUCO electric bow thruster 400 Volt 40 Hp proportional |
| Electricity system: | 12 / 24 / 230 / 400 Volt 230 Volt shore power connection |
| Batteries: | 2x navigation batterie(s) 2x starter batterie(s) generator Victron BMV-501 battery monitor |
| Battery charger: | Victron Phoenix battery charger 24/25 |
| Earth-leakage breaker: | present |
| Genny: | Jelmer Valk whisper set 35 kVA 230/400 Volt 1500 RPM |
| Solar panels: | 2x solar panel |
| Fresh water tank (approx.): | 1x 1500 litre steel tank(s) cemented tank(s) |
| Water pressure system: | Speck hydrophore pump |
| Hot water system: | boiler/water calorifier (230 Volt) |
| Holding tank (approx.): | 1x 400 litre steel tank(s) |
| Engineroom: | see photographs |
| Bilge pump: | general service pump 230 Volt with manifold also deckwash pump |
| Gas system: | no gas on board |
| Additional information: | 400 Volt air compressor 2x air bottle |
Accommodation
| Interior: | oak & various materials have been used see photographs |
| Insulation: | glass wool & Rockwool |
| Cabins: | 1 cabin |
| Berth: | 1x 2-pers |
| Lay-out plan (not to scale): | see attachment |
| Bathroom: | bath with shower hot & cold running water washbasin with hot & cold running water |
| Toilet / Heads: | lady's room: flush toilet washbasin cold running water men's room: flush toilet washbasin cold running water 2x tiled toilet |
| Cooker: | 4-burner hob electric cooker |
| Oven: | Rational CM6 combi steamer oven |
| Microwave: | present |
| Fridge / Refrigerator: | 1x combi bottles cooler & bier /beer /bière 1x bottles cooler 1x beer fridge 1x fridge / refrigerator |
| Freezer: | 1x freezer |
| Worktop: | stainless steel worktop |
| Washbasin: | 5x stainless steel sink |
| Water tap: | 3x hot & cold running water 2x cold running water |
| Headroom (approx.): | wheelhouse (approx.) 2,06 m aft (approx.) 1,95 m corridor / walkthrough (approx.) 1,83 m bathroom (approx.) 1,83 / 2,12 m cabin (approx) 2,62 m salon (approx.) 2,68 m toilet (approx.) 2,45 m bar (approx.) 2,67 m galley (approx.) 2,07 m |
| Additional information: | 2x beer tap Full charter inventory is present. 2x coffee machine |
Navigation equipment
| Navigation equipment: | Radio Zeeland RZ 9000 - RZ 7005/03 river autopilot (follow-up steering ) Radio Zeeland RZ 7005/03 rudder indicator Radio Zeeland RZ 8082/02 rate-of-turn indicator 2x Sailor RT144 VHF Cobra portable VHF Alewijnse Explorer A4 Automatic Identification System (AIS) Manacor PA-302 intercom clinometer navigation lights horn clearviewscreen compass Icom IC-M401Euro VHF Navman Tracker 5500 chartplotter / GPS |
Rigging and sails
| Rigging type: | brigantine (schooner brig) rigged |
| Mast: | 2x steel |
| Lowerable: | no |
| Boom: | 1x steel |
| Gaff: | 1x steel |
| Jib boom / Bowsprit: | steel bowsprit |
| Material of the sails: | Dacron |
| Sails: | inner yankee (UBS Sails) outer yankee (UBS Sails) jib (UBS Sails) square sail (UBS Sails) marssail (UBS Sails) staysail (UBS Sails) mainsail (UBS Sails) in 2022 werden deze zeilen voor het eerst gebruikt in 2022 these sails were used for the first time im Jahr 2022 wurden diese Segel erstmals eingesetzt en 2022, ces voiles ont été utilisées pour la première fois |
| Additional information: | 2 steel topmast(s) (2017) 1 sail cover bobstay pin rail |
Equipment
| Anchor equipment: | manual anchor winch 2x Spek anchor 2x anchor chain in hawse-hole warping drum |
| Bimini: | bimini top above aftdeck |
| Boarding ladder: | aluminium |
| Searail / Pulpit: | searail on bulwark guardrail around aftdeck |
| Dinghy: | RIB Mercury 25 Hp |
| Davits: | present |
| Safety: | life buoys life jackets rescue cushion(s) fire extinguishers fire alarm system fire blanket Automated External Defibrillator (AED) according to the certification requirements |
| Additional information: | aluminium gangway Survey report of the underwatership is available (05-2023) |
